Name: Laminar Air Flow
Brand: SaiLab Equipment

Description

SaiLab Equipment is a trusted manufacturer and supplier of Laminar Air Flow systems, ensuring a controlled, sterile working environment for laboratories, research centers, and pharmaceutical applications. Our horizontal and vertical Laminar Air Flow units are designed to maintain an ISO-classified clean air zone, preventing contamination of sensitive samples and equipment.

Key Features:

Efficient HEPA/ULPA Filtration: Captures 99.99% of airborne particles (≥0.3 microns).
Stainless Steel Work Surface: Ensures durability and easy cleaning.
UV Germicidal Lamp: Provides sterilization to maintain a contamination-free workspace.
Unidirectional Airflow: Maintains a consistent airflow pattern for optimal cleanliness.
Low Noise & Vibration Design: Ideal for precise laboratory operations.
Custom Sizes Available: Tailored solutions as per industry requirements.

Technical Specifications:

Feature	Specification
Airflow Type	Horizontal/Vertical
Filtration Efficiency	99.99% @ 0.3 microns (HEPA Filter)
Work Surface Material	Stainless Steel
Noise Level	≤65 dB
Illumination	Fluorescent Light & UV Lamp
Power Supply	220V / 50Hz
Customization	Available

SaiLab Equipment’s Laminar Air Flow units are widely used in microbiology labs, pharmaceutical industries, research institutions, and biotech companies, ensuring product protection and sterility.

Available Sizes:

Model	Dimensions (L x W x H)
SLF-2	2 x 2 x 2 ft
SLF-3	3 x 2 x 2 ft
SLF-4	4 x 2 x 2 ft
SLF-5	5 x 2 x 2 ft
SLF-6	6 x 2 x 2 ft

These size options cater to various workspace requirements, ensuring that clients can select a model that best fits their operational needs.

Product Specifications

Sr. No.	Description	Specification
1	Main Body	MS Powder Coated
2	Work Zone	Completely in Stainless Steel (Grade 304)
3	Height of Stand	650 mm
4	Filter Type	HEPA Filter
5	Efficiency	99.99%
6	Particle Retention	0.3 Micron
7	Pre-Filter	Disposable, Non-washable Polyester Fiber
8	Cleanliness	Class 100
9	Ultra Violet Tube Light	Class 100
10	Surface Illumination	Fluorescent Tube Light
11	Blower-Motor Assembly	Dynamically Balanced
12	Static Pressure Measurement	Magnehelic Gauge
13	Airflow Velocity	0.3 – 0.5 m/s
14	Noise Level	65 Decibels
15	Front Sash	Shatterproof Glass Door
16	Power Supply	230V AC, Single Phase, 50Hz
17	Standard Model	Inner: Stainless Steel (Grade 304), Outer: MS Powder Coated
18	GMP Model	Inner & Outer Body: Stainless Steel (Grade 304)

Applications:

Ideal for use in microbiology, biotechnology, pharmaceutical manufacturing, and research laboratories where a sterile environment is crucial. The Laminar Air Flow units protect sensitive samples and processes from particulate contamination, ensuring the integrity of experimental and production outcomes.

Why Choose SaiLab Equipment:

Quality Assurance: Our units are manufactured adhering to stringent quality standards, ensuring reliable performance and durability.
Customization: We offer both standard and GMP models, with inner and outer bodies available in Stainless Steel (304 grade) to meet specific client requirements.
Support: Dedicated customer service for consultation, installation, and after-sales support, ensuring a seamless experience from purchase to operation.
